Specifications:

• Form Factor: Tower


• Nominal Input Voltage (Vac): 230 � 10%


• Input Voltage Range (Vac): 165 ~ 290


• Input Frequency (Hz): 50 � 5, 60 � 5


• Input Frequency Detection: Auto-sensing


• Rated Input Current (A): 3.69


• Input Connector Type: AU


• Output Capacity (VA): 850


• Output Capacity (Watts): 425


• On Battery Waveform: Simulated Sine Wave


• On Battery Voltage(s) (Vac): 230 � 10%


• On Battery Frequency (Hz): 50 � 1%, 60 � 1%


• Automatic Voltage Regulation (AVR): Single Boost | Single Buck


• Overload Protection: Internal Current Limiting (Fuse)


• Outlet(s) - Total: 3


• Outlet Type: AU x 3


• Outlet(s) - Battery & Surge Protected: 3


• Typical Transfer Time (ms): 4


• Battery Runtime at 60W (min): 30


• Battery Runtime at 90W (min): 20


• Battery Runtime at 200W (min): 5.5


• Battery Typical Recharge Time (Hours): 6


• User-replaceable: No


• Battery Type: Sealed Lead-Acid


• Replacement Battery Pack (RBP): RBP0143


• Surge Suppression (Joules): 150


• EMI/RFI Filtration: Yes


• Phone/Network Protection RJ11/RJ45: 1-in | 1-Out


• LED Indicators: Power On | Line Mode | Battery Mode | Bypass Mode | Low Battery | Overload | UPS Fault


• HID Compliant USB Port(s): 1


• Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault


• Ethernet Data Transmission Speed: Up to 1Gbps


• Power Management Software: PowerPanel Personal (Recommended)


• Dimensions: 84 x 174 x 280mm


• Weight: 4.2kg


• Online Thermal Dissipation (BTU/hr): 34


• Certifications: RCM


• RoHS: Yes


• Generator Compatibility: Yes
